Creative

DISPLAYIT+ series

Indoor

Indoor product

Film Led Display Trasparente, flessibile ed ad alta luminosità.

Applicazione: Retail, Installation.

Caratteristiche.

  • Curved Splicing
  • Flexible
  • High Brightness
  • Ultra Light
  • Transparency
  • Creative Splicing
  • Ultra Thin
  • Fast & Easy Installation
  • Front Installation

Specifiche.

DISPLAYit+2 UNIDISPLAYIT+2.5-12100

DISPLAYit+3 UNIDISPLAYIT+3.9-25100

DISPLAYit+6 UNIDISPLAYIT+6.2-25100

DISPLAYit+2 UNIDISPLAYIT+2.5-12120

DISPLAYit+3 UNIDISPLAYIT+3.9-25120

DISPLAYit+3 UNIDISPLAYIT+3.9-25150

DISPLAYit+6 UNIDISPLAYIT+6.2-25120

DISPLAYit+6 UNIDISPLAYIT+6.2-25150

DISPLAYit+2 UNIDISPLAYIT+2.5-12150

DISPLAYit+3 UNIDISPLAYIT+3.9-25200

DISPLAYit+6 UNIDISPLAYIT+6.2-25200

Titolo

Pixel Pitch

Pixel Density

LED Type

Transparency

Panel Resolution

Panel Size

Profile Size

Panel Weight

Brightness

Max Power Consumption

Ave. Power Consumption

Input Voltage

Working Voltage for Module

Frame Rate

Pixel Configuration

Installation Method

Working Temperature

Working Humidity

Storage Temperature

Storage Humidity

IP Level

DISPLAYit+2 UNIDISPLAYIT+2.5-12100

2.5(H)/2.5(V) mm

160000 dots/mq

SMD1515

85%

50*400 dots

125*1000 mm

125*1025 mm

0.2 Kg/set

1000 cd/mq

608 W/mq

244 W/mq

AC100-240V

DC4.2V ±0.2V

60 -120 Hz

16 bit

PCB side glued, Hanging Up

-20℃ ~50℃

20%RH ~ 85%RH

-20℃ ~60℃

10%RH ~ 85%RH

IP20

DISPLAYit+3 UNIDISPLAYIT+3.9-25100

3.91(H)/3.91(V) mm

65536 dot/mq

SMD2121

92%

64*256 dots

250*1000 mm

250*1025 mm

0.4 Kg/set

3000/4500 cd/mq

684/577 W/mq

274/231 W/mq

AC100-240V

DC4.2V ±0.2V

60 -120 Hz

16 bit

PCB side glued, Hanging Up

-20℃ ~50℃

20%RH ~ 85%RH

-20℃ ~60℃

10%RH ~ 85%RH

IP20

DISPLAYit+6 UNIDISPLAYIT+6.2-25100

6.25(H)/6.25(V) mm

25600 dot/mq

SMD2121

95%

40*160 dots

250*1000 mm

250*1025 mm

0.4 Kg

5000 cd/mq

552 W/mq

221 W/mq

AC100-240V

DC4.2V ±0.2V

60 -120 Hz

16 bit

PCB side glued, Hanging Up

-20℃ ~50℃

20%RH ~ 85%RH

-20℃ ~60℃

10%RH ~ 85%RH

IP20

DISPLAYit+2 UNIDISPLAYIT+2.5-12120

2.5(H)/2.5(V) mm

160000 dots/mq

SMD1515

85%

50*470 dots

125*1175 mm

125*1200 mm

0.25 Kg/set

1000 cd/mq

608 W/mq

244 W/mq

AC100-240V

DC4.2V ±0.2V

60 -120 Hz

16 bit

PCB side glued, Hanging Up

-20℃ ~50℃

20%RH ~ 85%RH

-20℃ ~60℃

10%RH ~ 85%RH

IP20

DISPLAYit+3 UNIDISPLAYIT+3.9-25120

3.91(H)/3.91(V) mm

65536 dot/mq

SMD2121

92%

64*300 dots

250*1172 mm

250*1197 mm

0.5 Kg/set

3000/4500 cd/mq

684/577 W/mq

274/231 W/mq

AC100-240V

DC4.2V ±0.2V

60 -120 Hz

16 bit

PCB side glued, Hanging Up

-20℃ ~50℃

20%RH ~ 85%RH

-20℃ ~60℃

10%RH ~ 85%RH

IP20

DISPLAYit+3 UNIDISPLAYIT+3.9-25150

3.91(H)/3.91(V) mm

65536 dot/mq

SMD2121

92%

64*376 dots

250*1469 mm

250*1500 mm

0.6 Kg/set

2000-3000 cd/mq

526/414 W/mq

211/166 W/mq

AC100-240V

DC4.2V ±0.2V

60 -120 Hz

16 bit

PCB side glued, Hanging Up

-20℃ ~50℃

20%RH ~ 85%RH

-20℃ ~60℃

10%RH ~ 85%RH

IP20

DISPLAYit+6 UNIDISPLAYIT+6.2-25120

6.25(H)/6.25(V) mm

25600 dot/mq

SMD2121

95%

40*188 dots

250*1175 mm

250*1200 mm

0.5 Kg

5000 cd/mq

552 W/mq

221 W/mq

AC100-240V

DC4.2V ±0.2V

60 -120 Hz

16 bit

PCB side glued, Hanging Up

-20℃ ~50℃

20%RH ~ 85%RH

-20℃ ~60℃

10%RH ~ 85%RH

IP20

DISPLAYit+6 UNIDISPLAYIT+6.2-25150

6.25(H)/6.25(V) mm

25600 dot/mq

SMD2121

95%

40*236 dots

250*1475 mm

250*1500 mm

0.6 Kg/set

4500 cd/mq

502 W/mq

201 W/mq

AC100-240V

DC4.2V ±0.2V

60 -120 Hz

16 bit

PCB side glued, Hanging Up

-20℃ ~50℃

20%RH ~ 85%RH

-20℃ ~60℃

10%RH ~ 85%RH

IP20

DISPLAYit+2 UNIDISPLAYIT+2.5-12150

2.5(H)/2.5(V) mm

160000 dots/mq

SMD1515

85%

50*590 dots

125*1475 mm

125*1500 mm

0.3 Kg/set

1000 cd/mq

608 W/mq

244 W/mq

AC100-240V - 50-60Hz

DC4.2V ±0.2V

60 -120 Hz

16 bit

PCB side glued

-20℃ ~50℃

20%RH ~ 85%RH

-20℃ ~60℃

10%RH ~ 85%RH

IP20

DISPLAYit+3 UNIDISPLAYIT+3.9-25200

3.91(H)/3.91(V) mm

65536 dot/mq

SMD2121

92%

64*504 dots

250*1969 mm

250*2000 mm

0.8 Kg/set

1700-2550 cd/mq

520/414 W/mq

208/177 W/mq

AC100-240V - 50-60Hz

DC4.2V ±0.2V

60 -120 Hz

16 bit

PCB side glued, Hanging Up

-20℃ ~50℃

20%RH ~ 85%RH

-20℃ ~60℃

10%RH ~ 85%RH

IP20

DISPLAYit+6 UNIDISPLAYIT+6.2-25200

6.25(H)/6.25(V) mm

25600 dot/mq

SMD2121

95%

40*316 dots

250*1975 mm

250*2000 mm

1 Kg

3000 cd/mq

440 W/mq

176 W/mq

AC100-240V - 50-60Hz

DC4.2V ±0.2V

60 -120 Hz

16 bit

PCB side glued, Hanging Up

-20℃ ~50℃

20%RH ~ 85%RH

-20℃ ~60℃

10%RH ~ 85%RH

IP20

Chiedi più info
